Battery Type - Chemistry |
LiFePO₄ |
Nominal Voltage |
51.2 V |
Nominal Capacity |
100 Ah |
Energy Density |
5120 Wh |
Dimensions (LxWxH) |
607.7 * 362.5 * 162.3 (mm) |
Weight |
43 KG |
Ah Efficiency (Round-trip) |
>98% |
Max in Parallel |
15 PCS |
Voltage Range |
43.2 ~ 58.4 V |
Recommended Charge Voltage |
57.6 V |
Max Charge Voltage |
58.4 V |
Recommended Charge Current |
70 A |
Max Continuous Charge Current |
100 A |
Recommended Discharge Voltage |
44.8 V |
Max Discharge Voltage |
43.2 V |
Max Continuous Discharge Current |
100 A |
Cycle Life (0.5C, 25°C @ 80% DOD) |
6000 Cycles |
Storage Temperature |
-20°C to 60°C (Recommended -10°C to 35°C) |
Wi-Fi & Bluetooth App (Option) |
Yes |
Certification |
UN38.3 / MSDS / CE / IEC |
Warranty |
5 Years |
Compatibility |
and compatible with Fronus inverters
|
