Maximum PV Input Power |
9200W |
Rated Output Power |
8200W / 8200VA |
Output Voltage Waveform |
Pure Sine Wave |
Output Voltage Regulation |
230VAC ±5% |
Output Frequency |
50Hz |
Peak Efficiency |
93% |
Overload Protection |
3s@≥150% Load 5s@101%~150 Load |
Surge Capacity |
16400W For 5s |
Nominal DC Input Voltage |
48Vdc |
Cold Start Voltage |
46.0Vdc |
High DC Recovery Voltage |
62Vdc |
High DC Cut-Off Voltage |
63Vdc |
No Load Power Consumption |
70W |
Full Load |
8200W |
Maximum Main Load |
8200W |
Maximum Second Load Upto(Battery Mode) |
2733W |
Main Load Cutt Off Voltage |
52VDC |
Main Load Return Voltage |
54VDC |
Charging Algorithm |
3-Step |
AC Charging Current (Maxinum) |
100A |
Bulk Charging Voltage (Flooded Battery) |
58.4 |
Bulk Charging Voltage (AGM/Gel Battery) |
56.4 |
Floating Charging Voltage |
54Vdc |
Maximum PV Array Power |
9200W |
Nominal PV Voltage |
360Vdc |
PV Array MPPT Voltage Range |
90Vdc ~ 450Vdc |
Max PV Array Open Circuit Voltage |
500Vdc |
Maximum Charging Current |
160A |
Nominal Output Voltage |
220/230/240VAC |
Feed-In Grid Voltage Range |
195 ~ 253VAC |
Feed-In Grid Frequency Range |
49 ~ 51±1Hz / 59 ~ 61±1Hz |
Nominal Output Current |
35.6A |
Power Factor Range |
>0.99 |
Maximum Conversion Eciency (DC/AC) |
98% |
Input Voltage Waveform |
Sinusoidal (Utility or Generator) |
Nominal Input Voltage |
230Vac |
Low Loss Voltage |
170Vac ±7V (UPS) 90Vac ±7V (Appliances) |
Low Loss Return Voltage |
180Vac ±7V (UPS) 100Vac ±7V (Appliances) |
High Loss Voltage |
280Vac ±7V |
High Loss Return Voltage |
270Vac ±7V |
Maximum AC Input Voltage |
300Vac |
Nominal Input Frequency |
50Hz / 60Hz (Auto Detection) |
Low Loss Frequency |
40±1Hz |
Low Loss Return Frequency |
42±1Hz |
High Loss Frequency |
65±1Hz |
High Loss Return Frequency |
63±1Hz |
Output Short Circuit Protection |
Circuit Breaker |
Eciency (Line Mode) |
>95% (Rated R Load, Battery Full Charged) |
Transfer Time |
10ms For UPS 20ms For Applicance |
Safety Certification |
CE |
Operating Temperature Range |
-10˚ C to 50˚ C |
Storage Temperature |
-15˚ C to 60˚ C |
Humidity |
5% to 95% Relative Humidity (Non-Condencsing) |
Dimensions (D*W*H) mm |
500 x 390 x 130 |
Net Weight (KG) |
14.2 |
